Books Computers & Internet Programming Language and Programming

Jingdong book

PLC编程入门及工程实例

Name: PLC编程入门及工程实例
Brand: Jingdong book
SKU: 3118197001
Price: 34.18 USD
Availability: OutOfStock

{{__(":people-members", {'people': item.limit_people_count})}} {{ itemCurrency }}{{ item.valid_price }} {{ itemCurrency }}{{ item.invalid_price }} {{ itemDiscount }}

Ends in

{{ itemCurrency }}{{ priceFormat(item.valid_price / item.bundle_specification) }}/{{ item.unit }}

{{ itemCurrency }}{{ item.valid_price }} {{ itemCurrency }}{{ priceFormat(item.valid_price / item.bundle_specification) }}/{{ item.unit }} {{ itemCurrency }}{{ item.invalid_price }} {{itemDiscount}}

Sale ends in

Sale will starts after Sale ends in

{{ __( "Pay with Gift Card to get sale price: :itemCurrency:price", { 'itemCurrency' : itemCurrency, 'price' : (item.giftcard_price ? priceFormat(item.giftcard_price) : '0.00') } ) }} ({{ itemCurrency }}{{ priceFormat(item.giftcard_price / item.bundle_specification) }}/{{ item.unit }}) Details

Best before

Currently unavailable.

We don't know when or if this item will be back in stock.

Unavailable in your area.

Sold Out

Details

Full product details

Editer Recommend

1.内容依据初学者的学习特点编写
2.以应用广泛的西门子和欧姆龙两种品牌为例
3.列举了大量的工程应用实例

Content Description

本书介绍了PLC的基本概念，分类，特点，基本结构，工作原理和编程语言；PLC编程的基本要求和规则，PLC的程序设计的常用方法和典型应用编程，PLC控制系统设计的基本内容和步骤，PLC机型的选择，系统的安装调试方法；并分西门子和欧姆龙介绍了PLC的指令系统，用大量实例介绍了PLC在控制系统中的应用，后介绍了PLC通信与网络技术。
本书内容由浅入深，密切联系实际，可以帮助初学者尽快掌握PLC的基本知识技能。
本书可作为电工及电气技术人员的自学，培训用书，也可作为高等院校相关知识专业师生的教学参考用书。

Catalogue

第1章概述
1.1PLC的基本概念、分类、特点和应用1
1.1.1PLC的基本概念1
1.1.2PLC的分类1
1.1.3PLC的特点3
1.1.4PLC的应用4
1.2PLC的基本结构5
1.2.1中央处理器5
1.2.2存储器6
1.2.3输入、输出接口6
1.2.4电源8
1.2.5编程器8
1.3PLC的工作原理8
1.3.1PLC的等效电路8
1.3.2PLC的工作方式10
1.3.3PLC的工作过程10
1.4PLC的编程语言11
1.4.1PLC的软件组成11
1.4.2梯形图(LAD)编程语言12
1.4.3指令表(STL)编程语言12
1.4.4顺序功能图(SFC)编程语言13
1.5PLC主要产品品牌13
1.5.1西门子13
1.5.2欧姆龙15
第2章PLC的指令系统
2.1西门子的指令系统18
2.1.1数据类型及寻址方式18
2.1.2常用基本指令22
2.1.3常用功能指令37
2.2欧姆龙的指令系统53
2.2.1存储区分配53
2.2.2常用基本指令55
2.2.3常用功能指令70
第3章PLC的程序设计
3.1PLC编程的基本要求和规则85
3.1.1PLC程序设计的基本要求85
3.1.2梯形图编程的基本原则86
3.2PLC的程序设计的常用方法90
3.2.1经验设计法90
3.2.2顺序控制设计法92
3.2.3使用启保停电路的编程方法99
3.3PLC典型应用编程100
3.3.1系统启停控制100
3.3.2延时接通控制102
3.3.3延时断开控制103
3.3.4延时接通延时断开控制104
3.3.5脉冲发生器104
3.3.6闪烁信号(脉宽和周期可调的脉冲发生器)104
3.3.7定时器定时时间扩展105
3.3.8计数器计数值扩展106
3.3.9二分频107
第4章 PLC的系统设计
4.1PLC控制系统设计的基本内容和步骤108
4.1.1PLC控制系统设计的基本原则108
4.1.2PLC控制系统设计的基本内容109
4.1.3PLC控制系统设计的一般步骤109
4.2PLC机型的选择112
4.2.1选型原则112
4.2.2PLC型号的选择113
4.2.3PLC容量的估算114
4.2.4I/O模块的选择114
4.2.5分配输入/输出点115
4.3系统的安装115
4.3.1安装注意事项115
4.3.2PLC的安装与接线117
4.4系统调试120
4.4.1调试的方法120
4.4.2系统调试过程123
4.5PLC的维护与检修124
4.5.1维护检查124
4.5.2故障排除126
第5章 PLC在控制系统中的应用实例
5.1常用电动机启停电路的PLC控制130
5.1.1西门子PLC控制电路130
5.1.2欧姆龙PLC控制电路138
5.2常用灯光系统的PLC控制156
5.2.1西门子PLC控制电路156
5.2.2欧姆龙PLC控制电路163
5.3典型生产自动线的PLC控制168
5.3.1西门子PLC控制电路168
5.3.2欧姆龙PLC控制电路172
5.4其他常用系统的PLC控制183
5.4.1西门子PLC控制电路183
5.4.2欧姆龙PLC控制电路187
第6章 PLC通信与网络
6.1PLC通信基础知识194
6.1.1通信方式194
6.1.2通信介质196
6.1.3PLC常用通信接口198
6.1.4计算机通信标准201
6.2PC与PLC通信的实现204
6.2.1概述204
6.2.2PC与S7-200系列PLC通信的实现205
6.2.3PC与CPM1A系列PLC通信的实现207
6.3PLC网络210
6.3.1生产金字塔结构与工厂计算机控制系统模型210
6.3.2PLC网络的拓扑结构210
6.3.3PLC网络各级子网通信协议配置的规律213
6.3.4PLC网络中常用的通信方式214
6.4现场总线技术216
6.4.1现场总线概述217
6.4.2现场总线的特点与优点219
6.4.3几种有影响的现场总线221
6.4.4PROFIBUS-DP现场总线223
6.4.5CC-Link现场总线228
6.5PLC通信应用230
6.5.1西门子PLC通信应用230
6.5.2欧姆龙PLC通信应用241
参考文献254

Introduction

可编程控制器（PLC）由于具有可靠性高、逻辑功能强、体积小等一系列优点，在现代机械设备中得到了广泛应用，已成为现代工业控制的主要方式之一。社会上专门介绍PLC应用的书籍很多，但适合初学者自学的较少。为了培养电气工程技术人才，满足广大PLC初学者及从事电气工程技术工作各类人员的需要，我们组织编写了《PLC编程入门及工程实例》一书。
本书共分6章，兼顾实际应用非常广泛的西门子和欧姆龙两种品牌，介绍了PLC的基本概念、分类、特点和应用，PLC的基本结构，工作原理和编程语言等基本知识；PLC的指令系统；PLC的程序设计的常用方法和典型应用编程；PLC控制系统设计的基本内容和步骤，PLC机型的选择、系统的安装调试方法；并用大量实例介绍了PLC在控制系统中的应用；后介绍了PLC通信与网络技术。
本书由张应龙担任主编和统稿工作，杨宁川、王胜、王萍、梁健、胡旭参加了有关章节的编写工作。在编写过程中，参阅了有关教材、资料和文献，在此对有关专家、学者和作者表示衷心感谢。
在本书的编写过程中，江苏大学李金伴教授、杨宁川高级技师给予了精心的指导和热情的帮助，提出了许多宝贵的意见，全书由江苏大学李金伴教授担任主审，在此谨向他们表示衷心感谢。
本书以企事业单位中的电工初学者、电气技术工人和电气工程技术人员为主要对象，根据初学者学习的基础与PLC的特点，能使读者在较短的时间内初步掌握PLC编程的基本知识与技能。本书内容丰富、由浅入深、密切联系实际，可作为企事业单位中电工初学者、电气技术工人和电气工程技术人员的培训、自学和参考用书。
由于编者水平所限，编写时间比较仓促，书中不妥之处在所难免，恳请读者批评指正。
编者

Specifications

Brand

Jingdong book

Brand Origin

China
